1.Measurement Performance Measuring Parameters: Heading, Pitch, Roll Heading Accuracy: ±0.5° (after magnetic compensation) Tilt Accuracy: ±0.1° Heading Range: 0°~360°, Pitch & Roll: ±90° Resolution: 0.01° Update Rate: 1~10Hz adjustable Shock & Vibration Resistance Shock Resistance: 50g triaxial instantaneous impact Vibration Resistance: 5grms, 10~1000Hz full band 2.Electrical & Environmental Parameters Power Supply: DC 9~36V wide voltage Output Interface: RS485 Modbus-RTU Display: Onboard digital LCD screen for real-time data viewing Protection Grade: IP67 standard Operating Temperature: -40℃ ~ +85℃ Housing: Oxidized aluminum alloy, anti-corrosion & impact resistant EMC Compliance: EN61000 3.Core Functions & Advantages Integrated digital display, no extra monitor required for on-site data reading Automatic magnetic field compensation to offset ferromagnetic interference from vehicle metal structure Combined 3-axis attitude and heading measurement, one sensor for orientation & tilt detection Adjustable output frequency to match different control system response demands Industrial wide voltage design compatible with marine and engineering vehicle power supply Factory calibrated, simple one-click compensation operation on site 4.Structural Features Single M12 aviation connector for convenient wiring. Integrated aluminum enclosed housing with embedded digital display window, fully dustproof and waterproof for outdoor cabin installation. Internal isolated magnetic sensing module reduces electromagnetic interference. 5.Application Fields Satellite communication vehicle automatic tracking, marine vessel heading monitoring, engineering machinery positioning navigation, mountain rescue vehicle orientation detection, mobile radar azimuth adjustment, outdoor robot attitude navigation.
