1.Measurement & Switch Parameters Measuring Axis: LCA331 single-axis; LCA332 dual-axis (Pitch & Roll) Optional Trigger Angle: ±2°, ±5°, ±10°, ±15°, ±30° Angle Repeatability: ≤0.04° Adjustable Anti-shock Delay: 0.1s ~ 5s to avoid false trigger Output Type: NPN/PNP switch signal Shock & Vibration Resistance Shock Resistance: 50g triaxial instantaneous impact Vibration Resistance: 5grms, 10~1000Hz full frequency band 2.Electrical & Environmental Parameters Power Supply: DC 9~36V wide voltage Protection Grade: Standard IP67 Operating Temperature: -40℃ ~ +85℃ Housing: Oxidized aluminum alloy, shock and corrosion resistant EMC Compliance: EN61000 industrial electromagnetic standard 3.Core Functions & Advantages High repeatability angle threshold trigger for equipment safety interlock Digital switch output directly connected with PLC, alarm lights and buzzers Adjustable delay filtering effectively eliminates mis-trigger caused by slight vibration Single/dual axis options to meet different one-way or two-way tilt detection requirements Compact sealed aluminum casing, easy outdoor installation Factory calibrated with preset angles, plug and play without secondary debugging 4.Structural Features LCA331 and LCA332 adopt single M12 aviation connector design for simple wiring. Fully enclosed integrated aluminum shell achieves dustproof and waterproof performance, suitable for fixed mounting on various mechanical equipment. 5.Application Fields Aerial work platform tilt protection, tower crane anti-overturn alarm, hydraulic platform leveling limit, solar bracket deviation monitoring, construction machinery safety interlock, automated equipment over-tilt stop control.
