1.Measurement Performance Measuring Axis: RNA816T single axis; RNA826T dual axis (Pitch & Roll) Measuring Range: Optional ±10°, ±30°, ±60°, ±90° Resolution: 0.001° Static Accuracy: ±0.02° (@25℃) Temperature Drift: ±0.008°/℃ (-40℃ ~ +85℃) Response Time: Adjustable from 0.1s to 10s Shock & Vibration Resistance Shock Resistance: 50g triaxial instantaneous impact Vibration Resistance: 5grms (10~1000Hz full frequency band) 2.Electrical & Environmental Parameters Power Supply: DC 9~36V wide voltage input Output Interface: CAN2.0A bus Protection Grade: Standard IP67, IP68 customized available Operating Temperature: -40℃ ~ +85℃ Housing: Oxidized aluminum alloy, anti-corrosion & anti-impact MTBF: ≥100000 hours EMC Compliance: EN61000 industrial electromagnetic standard 3.Core Functions & Advantages Industry-leading ultra-high static precision for deformation and leveling monitoring Built-in full temperature compensation to minimize zero drift under extreme temperature Single/dual axis optional to satisfy diverse single or dual-angle measurement demands Standard CAN2.0A interface, perfectly matched with vehicle controllers and industrial PLC Compact integrated structure, easy to mount on metal brackets Factory overall calibration, plug-and-play without secondary debugging 4.Structural Features Both RNA816T-CAN2.0A and RNA826T-CAN2.0A adopt single M12 aviation connector design for convenient wiring. Fully enclosed sealed aluminum shell realizes dustproof and waterproof performance, suitable for fixed outdoor installation. 5.Application Fields Applied to bridge deflection monitoring, building tilt detection, solar panel tracking, hydraulic platform leveling, tower crane safety monitoring, dam deformation observation and automatic equipment static angle control.
