1.Measurement Performance Sensing Axis: Single-axis gyroscope Measurement Range: ±100°/s, ±200°/s optional Output Signal: Analog voltage 0.5~4.5V Zero Voltage: 2.5V static output Scale Factor: Standard 20mV/(°/s) Non-linearity ≤0.2%FS, Repeatability ≤0.1%FS Response Bandwidth: 0~50Hz Zero Drift: ≤0.08°/s Shock & Vibration Resistance Vibration Resistance: 7grms, 10~1000Hz full frequency band Shock Resistance: 70g three-axis instantaneous impact 2.Electrical & Environmental Parameters Power Supply: DC 5V stabilized power supply Current Consumption: ≤18mA Protection Grade: IP64 aluminum alloy sealed housing Operating Temperature: -40℃ ~ +75℃ EMC Compliance: EN61000 industrial electromagnetic standard 3.Core Functions & Advantages Analog voltage direct output, no decoding required, simple acquisition circuit and low application cost Single-axis independent angular velocity measurement, dedicated to single-direction rotation monitoring MEMS micro-mechanical chip, small volume, light weight, easy embedded installation Stable zero point and low drift, reliable long-term continuous operation Metal sealed shell with dustproof and anti-interference capability, suitable for factory workshop environment Wide temperature working range, normal output under high and low temperature conditions Simple three-wire wiring (power, GND, signal), convenient on-site wiring debugging 4.Structural Features Mini rectangular aluminum alloy integrated housing, built-in MEMS sensing core and signal conditioning circuit. Lead wire external outlet, reserved two fixing mounting holes, single sensitive axis marked clearly for installation direction confirmation. 5.Application Fields Small rotating machinery speed detection, intelligent car body rotation monitoring, industrial manipulator rotation feedback, AGV single-axis angular velocity measurement, pan-tilt rotation speed control, small unmanned vehicle attitude auxiliary detection, automation equipment rotation closed-loop control.
