1.Measurement Performance Output Data: Heading, Pitch, Roll Static Heading Accuracy: ±0.4° Dynamic Heading Accuracy: ±0.8° under motion and vibration Tilt Accuracy: ±0.1° Measuring Range: Heading 0°~360°, Pitch & Roll ±90° Resolution: 0.01° Adjustable Update Rate: 1Hz ~ 50Hz Shock & Vibration Resistance Shock Resistance: 60g triaxial instantaneous impact Vibration Resistance: 8grms, 10~1000Hz full frequency band 2.Electrical & Environmental Parameters Power Supply: DC 3.3V / 5V optional Communication Interface: TTL / RS485 Modbus-RTU Protection Grade: IP54 integrated plastic enclosure Operating Temperature: -40℃ ~ +85℃ EMC Compliance: EN61000 industrial electromagnetic standard 3.Core Functions & Advantages Professional dynamic fusion algorithm guarantees reliable azimuth output while equipment moves or vibrates Integrated sealed plastic housing for direct installation, no secondary shell processing required One-click automatic magnetic compensation to correct ferromagnetic distortion errors High adjustable refresh rate supports fast dynamic attitude tracking Low power consumption, suitable for battery-powered mobile and unmanned equipment Standard wire outlet design for simple wiring and connection with controllers 4.Structural Features Compact all-in-one plastic enclosure with built-in PCB sensing unit and external lead wires. Independent isolated magnetic sensing area avoids electromagnetic interference from power circuits. Small overall dimension fits installation on vehicles, engineering machinery and marine equipment. 5.Application Fields UAV dynamic navigation, engineering vehicle azimuth adjustment, marine vessel moving attitude monitoring, unmanned ground robots, mobile surveying equipment, mobile radar & satellite antenna automatic tracking systems.
