MF58 Series Glass Sealed Temperature Measuring NTC Thermistor
| Item No : | MF58 |
| Resistance Value : | 0.1~3780 kΩ |
| Resistance Tolerance : | ±1%, ±2%, ±3%, ±5%, ±10% |
| B Value 25/50 (K) : | 3100~4500 K |
| Temperature Range : | -55~+250 °C |
| Thermal Dissipation Coefficient : |
≥2 mW/°C |
| Thermal Time Constant : | ≤20 s |
| Maximum Rated Power : | ≤50 mW |
PRODUCT INTRODUCTION
Product Description
The MF58 series is a glass sealed product that is resistant to high temperatures, including leads, and can be welded with a soldering iron.
Product Features
1.Application scope:
- Temperature control and detection of household appliances (such as air conditioners, microwaves, induction cookers, toasters, electric fans, electric heaters, etc.)
- Temperature detection or compensation of office automation equipment (such as copiers, printers, etc.)
- Mobile phone batteries and battery packs.
- Temperature compensation for instrument coils, integrated circuits, quartz crystal oscillators, and thermocouples.
2. Features:
- Good stability and high reliability
- Wide resistance range and high accuracy..
- Can be used in harsh environments such as high temperature and humidity
- Small size, light weight, and sturdy structure..
- Easy for automated installation..
- Heat sensitivity should be fast and high
3. Installation method:
- Lead soldering iron welding
